Donaldson P506196 Lube Spin-on Oil Filter for Chinese Engines (equiv: JX85100)

No reviews yet Write a Review

Afterpay Terms & Conditions
Make 4x interest-free
payments of
$13.75 AUD fortnightly

ZipPay Terms & Conditions
Spend up to $1000.
Weekly, Fortnightly
or Monthly Repayments

0.70 KGS
Calculated at Checkout

Donaldson P506196 Lube Spin-on Oil Filter for Chinese Engines (equiv: JX85100)


Donaldson Lube Spin-on Oil Filter P506196 suits:
Chinese Engs, Foton FT404, FT504, Taishan TS554 Tractors and Generators using numbers; CX85100C, JX85100C, WB202C

Note: If thread size is M20 x 1.5 - CLICK HERE to purchase Donaldson P550934

Cross reference:
Clarcor Filtration (China) CX85100C, JX85100C, WB202C

Outer Diameter: 93mm (3.66 inch)
Thread Size: M24x2
Length: 130mm (5.12 inch)
Gasket OD: 72mm (2.83 inch)
Gasket ID: 63.2mm (2.49 inch)
Efficiency: 99% 38 micron
Anti-Drainback Valve: No
Bypass Valve Setting LR: 1.17 bar (17 psi)
Bypass Valve Setting HR: 1.76 bar (26 psi)
Media Type: Cellulose
Collapse Burst: 6.86 bar (99 psi)

New oils play a vital part in protecting engines by reducing friction and wear, cooling engine parts, sealing combustion chambers, cleaning engine components and inhibiting corrosion. Lube Oil filters also play a critical role in protecting engines by removing damaging contaminants from the oil.

Lube Oil filters trap oil contaminants in two ways:
:: Some particles adhere to the filter media as the oil flows through the filter. These particles attach themselves to the media surface without plugging the media pores.
:: Other particles are trapped in the filter media by the pressure of the oil as it flows through the filter.

Donaldson Lube / Oil Filters
Donaldson lube filters keep oil clean and engines running at peak performance by capturing contaminants that can cause engine damage. Achieve peak engine and equipment performance with Donaldson's complete line of oil filters for diesel engines - in both standard life and Donaldson Blue. We carry a complete line of oil filters for diesel engines – in both standard life and Donaldson Blue for extended service intervals.

If unsure of the part's Vehicle Application & Fitment:
Find Your Vehicle using our Parts Finder / REGO Search Widget
Click this LINK: Find My Vehicle/ REGO Search
